Edson “Mechanical Shift” Clutch and Throttle Control is designed for use with 64 Series (Edson #735) Transmission Cables and 33 Series (Edson #734) Throttle Cables.
Only for Edson Pedestals #334, 335, 336 and 337 with 6-7/8" diameter tops.
The clutch handle is 10”(254mm) long to provide increased shifting leverage for Atomic 4 and other hard to shift transmissions. The Throttle Handle is polished Stainless and clearly marked for “Fast” and “Slow” speeds. A Throttle Friction Adjustment Screw is a standard feature.
Hardware
Throttle set screw (bottom side): 8-32 x 3/8" F.H.
Clutch set screw (bottom side): 8-32 x 1/2" R.H.
Throttle friction adjustment screw (top side): 1/4"-20 x 1/2" nyloc H.H.
EB396 - Engine Control Instructions (#870, #816, #751) - Manual
